DEP events at Newtown Creek Waste Water Treatment Plant

leave a comment »

Everybody’s friends at the DEP have asked if I could share these invites to upcoming public events with you, Lords and Ladies of the Pentacle.

I’ll be busy on the 21st of course, but will make sure that everyone onboard waves when we’re passing by on the boat.

Lastly:

It is critical for you to purchase tickets for the Newtown Creek Cruise soon. We’re filling up rapidly and seating is limited. Your humble narrator is acting as chairman for this journey, and spectacular guest speakers are enlisted to be onboard. Click here to order tickets. Something I can promise you, given the heavy rain we’re having at the beginning of this week, is that the Newtown Creek will be especially photogenic on Saturday. Current forecasts call for light fog, possible early morning showers (we leave the dock at 10- late morning) and clouds clearing around noon! Photographers in Greenpoint, Long Island City, and beyond- this is going to be hyperfocal MAGIC.

From workingharbor.com

May 21st, Newtown Creek Cruise:

Explore Newtown Creek by Boat

Saturday, 21 May, 2011

Pier 17, South Street Seaport.

Departs 10 am sharp

Returns 1 pm

Price: $60

Join us for a special water tour with expert narration from historical and environmental guest speakers.

There are limited tickets available on the MV American Princess for a very rare tour of Newtown Creek. Guest narrators will cover points of industrial and historical interest as well as environmental and conservation issues during your three-hour exploration. New York’s forgotten history will be revealed – as well as bright plans for the creeks future.

MV American Princess is a large, comfortable vessel with indoor and outdoor seating. Complimentary soft drinks and a tour brochure are included.

Cruise runs rain or shine

Queries? Contact Tour Chairman Mitch Waxman: waxmanstudio@gmail.com

Hosted by Hidden Harbor Tours ® in association with the Newtown Creek Alliance.

Click here to order tickets

colossal and protuberant

leave a comment »

– photo by Mitch Waxman

There I sat, broken hearted…

Somehow that old Brooklyn Public School aphorism was on my mind as I scuttled along the street ends of Greenpoint. These shots were attained at India Street’s junction with the East River and depict the shield wall of a Shining City as viewed from the collapsing pierages of an ancient and crumbling competitor.

– photo by Mitch Waxman

It’s difficult for us to think of the Boroughs as separate cities… well, it’s hard to imagine Brooklyn, Queens, and the Bronx as separate while with Staten Island it’s quite easy… but they were. This location upon which I was standing was, until quite recently (from a historical perspective), heavily industrialized. A workshop, this section of Greenpoint is in many ways responsible for the ascendency of Manhattan over not just it’s local competition but the Nation itself.

– photo by Mitch Waxman

This is another of the zones which the City fathers has designated for whatever they call “urban renewal” these days, and plans are both afoot and underway to convert certain structures to residential use (such as the “Pencil Factory”) or to clear away the existing building stock to make way for new construction.

The good news, or bad depending on your perspective, is that a condition set forward to the real estate interests by the City is that a waterfront pedestrian concourse not unlike the one nearing completion across the Newtown Creek in Long Island City must be built in return for certain laxities of enforcement regarding the zoned height of waterfront development.

At least there’ll still be a place down by the water where the kids in Greenpoint can go and dream of an age when you needn’t have to commute to get to work.

Additionally, the following event will be happening in Greenpoint on May 4th, 2011. I’ve met Shawn Shafner and he’s got a LOT of good stuff to say about some very bad stuff indeed. I’ll be there- at the Temple of Cloacina- how about you, Citizen?

Text from the flyer with links:

Water for Cities: Responding to the Urban Challenge*

Moderated by Shawn Shafner of The People’s Own Organic Power Project www.thePOOPproject.org

Wednesday, May 4th 2011 6:30 pm – 8:30 pm Talks followed by a panel discussion

Visitor Center at Newtown Creek 329 Greenpoint Avenue Brooklyn, New York 11222

The Speakers are: Frederik Pischke Interagency Water Advisor UN-Water, Vyjayanthi Rao Assistant Professor of Anthropology New School for Social Research, New York, Jennifer Farmwald Project Manager Water Supply Infrastructure & Watershed Assessment NYC Environmental Protection.

Visit DEP’s website at www.nyc.gov/dep Follow us at www.facebook.com/nycwater


Sludge Boats, baby, Sludge Boats

with 15 comments

M/V Red Hook DEP Sludge Vessel – photo by Mitch Waxman

After processing at a water treatment facilities, which the City of New York’s DEP manages 14 of (including the vast Temple of Cloacina called the Newtown Creek Wastewater Treatment Plant), the concentrated sludge distillate produced by municipal sewage plants requires “dewatering” – it must be reduced into a semi solid called “cake”. Not every one of the 14 wastewater treatment plants has a dewatering facility, so the sludge needs to get from point A to point B via a the fleet of Sludge Vessels.

Pictured above is the sludge dock in Greenpoint, with the M/V Red Hook at dock, at the mouth of the Newtown Creek. Flowing from that aforementioned temple of “the Venus of the Sewers” to a gigantic holding tank via mechanical means, it is then pumped out to the dock and the waiting sludge boat.

from nyc.gov

Preliminary treatment

Several stories underground, wastewater flows into the plants from sewers connected to New York City’s homes and businesses. The incoming wastewater, called influent, passes through screens consisting of upright bars, spaced one to three inches apart. These bars remove large pieces of trash including rags, sticks, newspaper, soft drink cans, bottles, plastic cups and other similar items. This protects the main sewage pumps and other equipment. The garbage is transported to landfills. The main sewage pumps then lift the wastewater from the screening chamber to the surface level of the plant.

Primary treatment

Next, the wastewater enters primary settling tanks, also called sedimentation tanks, for one to two hours. The flow of the water is slowed, allowing heavier solids to settle to the bottom of the tank and the lighter materials to float. At the end of the process, the floatable trash, such as grease and small plastic material, rises and is skimmed from the top of the tanks surface.

The settled solids, called primary sludge, are then pumped through cyclone degritters — devices that use centrifugal force to separate out sand, grit (such as coffee grinds) and gravel. This grit is removed, washed and taken to landfills.

The degritted primary sludge is pumped to the plant’s sludge handling facilities for further processing. The partially treated wastewater from the primary setting tanks then flows to the secondary treatment system.

M/V North River DEP Sludge Vessel – photo by Mitch Waxman

The 1.3 billion gallon a day flow of New York City’s sewage should be defined as a third river. That’s 1,300,000,000 gallons a day or 474,500,000,000 gallons of night soil a year. 1.3 billion is the population of China.

Pictured above is the DEP Sludge Vessel M/V North River, a veteran, she was launched at Maryland Shipbuilding in 1974. Just under 324 foot long, North River can carry 102,000 cubic feet of evil juice and weighs in at 2,557 gross tons.

from nyc.gov

Secondary treatment

Secondary treatment is called the activated sludge process. This is because air and “seed” sludge from the plant treatment process are added to the wastewater to break it down further. Air pumped into large aeration tanks mixes the wastewater and sludge that stimulates the growth of oxygen-using bacteria and other tiny organisms that are naturally present in the sewage. These beneficial microorganisms consume most of the remaining organic materials that are polluting the water and this produces heavier particles that will settle later in the treatment process.Wastewater passes through these bubbling tanks in three to six hours.

The aerated wastewater then flows to the final settling tanks which are similar to the primary settling tanks. Here the heavy particles and other solids settle to the bottom as secondary sludge. Some of this sludge is re-circulated back to the aeration tanks as “seed” to stimulate the activated sludge process. The returned sludge contains millions of microorganisms that help maintain the right mix of bacteria and air in the tank and contribute to the removal of as many pollutants as possible.

The remaining secondary sludge is removed from the settling tanks and added to the primary sludge for further processing in the sludge handling facilities.Wastewater passes through the settling tanks in two to three hours and then flows to a disinfection tank.

Disinfection

Even after primary and secondary treatment, diseasecausing organisms may remain in the treated wastewater. To disinfect and kill harmful organisms, the wastewater spends a minimum of 15-20 minutes in chlorine-contact tanks mixing with sodium hypochlorite, the same chemical found in common household bleach. The treated wastewater, or effluent, is then released into local waterways. Disinfection is an essential step because it protects the health of people who use local beaches and enjoy other recreational activities on or near the water.

M/V Newtown Creek DEP Sludge Vessel – photo by Mitch Waxman

Identical in dimension and capacity to the North River, the 1967 vintage DEP Sludge Vessel M/V Newtown Creek passed under mighty Triborough and crossed Hells Gate. M/V Newtown Creek was laid down by the Wiley Manufacturing Co. Back in the days of ocean dumping, these ships were amongst a small fleet of tugs, barges, and older sludge boats that would “do the deed“.

from nyc.gov

Sludge treatment

The following are typical stages of the sludge treatment process.

Thickening

The sludge produced by primary and secondary treatment is approximately 99% water and must be concentrated to enable its further processing. Thickening tanks allow the sludge to collect, settle and separate from the water for up to 24 hours. The water is then sent back to the head of the plant or to the aeration tanks for additional treatment.

Digestion

After thickening, the sludge is further treated to make it safer for the environment. The sludge is placed in oxygenfree tanks, called digesters, and heated to at least 95 degrees Fahrenheit for between 15 to 20 days. This stimulates the growth of anaerobic bacteria, which consume organic material in the sludge. Unlike the bacteria in the aeration tanks, these bacteria thrive in an oxygen-free or “anaerobic” environment. The digestion process stabilizes the thickened sludge by converting much of the material into water, carbon dioxide and methane gas. The black sludge that remains after digestion has the consistency of pea soup and has little odor. This is called digested sludge.

Methane gas is often used as an energy source at the City’s wastewater treatment plants. The gas may be used in engines to produce electricity or directly drive plant equipment. Gas is also used in boilers to provide heat for digestion and plant-wide buildings. Currently, DEP and the New York Power Authority (NYPA) have jointly installed fuel cells at four of the City’s water pollution control plants; 26th Ward, Red Hook, Oakwood Beach and Hunts Point. Fuel cells convert the methane gas and carbon dioxide into heat and electricity that is then used to operate the plants. This technology contributes to New York City’s efforts to enhance clean air operations at its facilities. There is a significant reduction in air emissions as a result of using fuel cells.

Digester sludge is pumped from sludge storage tanks to a dewatering facility. At some treatment plants, where there are no dewatering facilities on site, the sludge is transported for processing through a pipeline or by a sludge boat to a plant that has a dewatering facility.

M/V Newtown Creek DEP Sludge Vessel, close-up – photo by Mitch Waxman

Once requiring a crew of as many of 20, the City now runs these ships with a mere 6. Semiautomated, M/V Newtown Creek and North River are nevertheless more than twice the size of the original model Sludge Vessels like the Owl’s Head.

from nyc.gov

Sludge dewatering

Dewatering reduces the liquid volume of sludge by about 90%. New York City operates dewatering facilities at eight of its 14 treatment plants. At these facilities, digested sludge is sent through large centrifuges that operate like the spin cycle of a washing machine. The force from the very fast spinning of the centrifuges separates most of the water from the solids in the sludge, creating a substance knows as biosolids. The water drawn from the spinning process is then returned to the head of the plant for reprocessing. Adding a substance called organic polymer improves the consistency of the “cake”, resulting in a firmer, more manageable product. The biosolids cake is approximately 25 to 27 percent solid material.

Written by Mitch Waxman

November 15, 2009 at 11:07 am
